Product Details:
|
| Model: | HSKT10 | Table Size: | 200 X 250 |
|---|---|---|---|
| Specimen Max Weight(kg): | 10 | Shock Pulse: | Half Sine Wave |
| Acceleration Range (m/s2): | 20----2000 | Pulse Duration Range (ms): | 0.2~18 |
| Highlight: | shock and drop testing,mechanical testing equipment |
||
High Speed Shock Test System with Half Sine Pulse, 500G 1ms,1500G 0.5ms
High Speed Shock Test Systems were developed to achieve the most demanding defense, aerospace, and electronics shock testing specifications. These highly specialized shock systems can generate incredible impact velocities.
Parameters:
| Model | HSKT10 | HSKT25 |
| Table size (mm) | 200x250 | 300x300 |
| Shock pulse | Half sine | |
| Maximum Specimen Weight(Kg) | 10 | 25 |
| Acceleration Range(G) | 20 ~ 2000 | 20 ~ 10000 |
| Pulse Duration (ms) | 0.2~18 | 0.2~18 |
| Machine Dimension(cm) | 660x700x2380 | 1350x1250x3300 |
| Utility Requirements |
AC220V 50Hz 5A,Air pressure: more than 0.5Mpa | |
| Machine Weight(Kg) | 820 | 1850 |
Features
Warranty: 12 months from delivery, lifelong time maintainance.
After-sale service: feedback within 24 hours after get the call or email.
Service: OEM, ODM
Certificate: China official third-party calibration report / CE Certification
Customer Service
Service timeliness
When a fault report is received from customer〈including telephone, fax and email〉:
LABTONE will respond within 4-8 hours (working time), provide solutions and eliminate faults within 12-24 hours. After the equipment's guarantee period ended, supplier still has obligation to provide users with technical supports and after-sales services.
